Treatment Plant Set-up

Author/Compiled by
Félicien Mazille (Aquasis, cewas – international centre for water management services)
Dorothee Spuhler (seecon international gmbh)
Executive Summary

Centralised drinking water treatment plants treat large amounts of water from many households in one single spot and consequently most often require more operation and maintenance and the construction of a water distribution system. Semi-centralised drinking water treatment plants are middle-scaled units e.g. on community level. These systems are most often designed to remove several types of contaminants from anthropogenic or natural origin: suspended and dissolved solids, ions (metals, fluorine, phosphates, nitrates), organic compounds (organic micropollutants, natural organic matter), and microorganisms (bacteria, viruses). As there is no water treatment method able to remove all these contaminants in one step semi-centralised and centralised treatment often needs multistep plants, which combine several techniques to purify water. Here a general overview of plant set-up for drinking water production is given.

Advantages
Very efficient and reliable for purifying water
Can be adapted to any kind of water
Relatively low cost for drinking water production
Disadvantages
Skilled labour, technical equipment, electricity and chemicals required to design and operate the plant
Plant has to be continuously controlled and maintained
High initial investment costs to build infrastructure
In Out

Precipitation, Freshwater

Drinking Water

Factsheet Block Title
Introduction
Factsheet Block Body

Drinking water treatment plants involve several consecutive processes, which remove solids, organic and inorganic pollutants, some metals and pathogenic microorganisms. The treatment plant set-up should be designed to take into account the quality of water being treated. In general, water treatment can be divided into: primary treatment to remove solids; secondary treatment to remove organic compounds as well as nitrogen and phosphorous; and tertiary treatment for disinfection.

Different sizes of treatment plants exist like centralised plants for big cities requiring a developed distribution system and semi-centralised plants adapted to provide drinking water to smaller communities at the point of use (POU).

Factsheet Block Title
Drinking water treatment plants
Factsheet Block Body

(Adapted from EPA 1999)

There is no precise method for treating surface water because of the various qualities of water that exists. Groundwater typically requires less treatment than water from lakes, rivers and the sea. Nevertheless, a series of conventional processes can be identified; they are presented in the figures below.

 General set-up of a drinking water treatment plant and example of the city of Tulsa. Source: BOULDER (2011), TULSA (2011)

General set-up of a drinking water treatment plant and example of the city of Tulsa. Source: BOULDER (2011); TULSA (2011)

In general the treatment of fresh water involves the following key steps:

Primary Steps

  • Aeration: The water is mixed to liberate dissolved gases and to suspend particles in the water column. Sometimes a pre-oxidation step is also performed at this stage.
  • Coagulation-Flocculation: In this step coagulants are added to remove the suspended particles (clay, organic material, metals, microorganisms), which stick to the coagulants forming heavy particles.
  • Sedimentation: The heavy particles (flocs) settle to the bottom leading to clear water.

Secondary Step

Tertiary Step

  • Disinfection: The water is now largely free of particles, organics and microorganism and is now treated to destroy any remaining disease-causing pathogens. This is commonly done with chlorination, ozonation, hydrogen peroxide, or UV radiation (similar to the point of use UV tubes). The water is then sent to the pumping station for distribution to homes and businesses. Chlorination is the most widely used disinfection method because it permits maintaining residual chlorine at a level efficient enough to guarantee the absence of microorganism until the water has reached its point of use.

When drinking water is produced from the sea, the water is desalinated by electrolysis or membranes such as reverse osmosis or by a solar process desalination.

Factsheet Block Title
Operation and maintenance
Factsheet Block Body

(Adapted from CWEA 2004)

Drinking water treatment plant operation and maintenance includes the following tasks:

  • Operate and adjust equipment controls to purify and clarify water.
  • Inspect equipment and monitor operating conditions, meters, and gauges to determine load requirements and detect malfunctions.
  • Add chemicals, such as ammonia, chlorine, and lime, to purify and disinfect water and other chemicals, such as ferric chloride, peroxide, and polymers, to enhance water treatment.
  • Collect and test water samples, using test equipment.
  • Record operational and laboratory data, observations of processes, and meter and gauge readings on specified forms.
  • Clean and maintain tanks, basins and filter beds, using hand tools and power tools.
  • Maintain, repair, and lubricate equipment, using hand tools and power tools.

Many of these tasks can be automated in modern treatment plants but trained operators and engineers are still required to control and maintain the system. Moreover, operation of the treatments also requires a significant amount of chemicals, which might not be available in little industrialised or remote areas.

Required energy input is significant. In Switzerland, required energy input for treatment and distribution of drinking water, including abstraction, is relatively low (around 0.4kWh/m3) due to the excellent quality of groundwater. In case of polluted or seawater treatment in semi-centralised plants, the required input is higher (around 1-2 kWh/m3). Smaller drinking water treatment plants may be installed at semi-centralised level or point of use in order to minimise energy requirements for distribution.

Factsheet Block Title
Average costs of water treatment plants
Factsheet Block Body

The cost of high quality municipal drinking water including transport is between less than 1 $/m3 in the US and more than 2 $/m3 in Denmark and Germany (CLARK 2007). The cost of drinking water from semi-centralised treatment plants operating in developing countries depends on water source quality and capacity. In the case of seawater and polluted sources it is typically around 1-2 $/m3. An important initial investment is required to build the treatment plant, which should be designed properly taking into account water composition to minimise the costs.

Factsheet Block Title
Alternative: ecosystems as water suppliers
Factsheet Block Body

Conservation or restoration of ecosystems is a good strategy to simplify and reduce the costs induced by drinking water treatment plants. If the water body has a good quality, drinking water can be obtained without any treatment. Therefore, wastewater treatment and integrated water resource management are crucier treatmenal to sustainable drinking water supply.

Another interesting alternative to improve the quality of influent water and lower the costs of treatment is bank filtration. This is done for instance in Basel, New York or Vienna.

In the city of Basel (166,000 inhabitants), the quantity of groundwater is insufficient to meet the city’s needs. Some 120,000 m3 of water per day are treated from the River Rhine through a mechanical filtration installation equipped with a quartz sand filter to remove the sediment. It then runs into small channels through a forest where it is infiltrated into the subsoil and thereby cleaned before reaching the groundwater (VERMONT 2004).

The natural systems of upstate New York's Catskill/Delaware watershed provide most of the City's drinking water. Rather than spending $8 billion on a water treatment facility in New York City, New York State opted to spend $1 billion to restore the watershed that provides the City’s drinking water (ESA 2012).

Factsheet Block Title
At a glance
Factsheet Block Body

Working principle

Combines several processes (e.g. aeration, coagulation-flocculation, filtration, disinfection) to remove a wide variety of contaminants present in water.

Capacity/adequacy

Sophisticated combination of water treatment processes. Skilled labour required to guarantee the performance of each process.

Performance

Efficient for all kinds of water when treatment plants are adequately designed and set up.

Costs

Relatively high implementation and operation costs because of high inputs of labour, chemicals and electricity.

Self-help compatibility

The incoming water and treated water quality has to be monitored to optimise each step of the plant.

O&M

Continuous operation and maintenance staff is required.

Reliability

Highly reliable if the treatment plant is well maintained.

Main strength

Very efficient for any kind of water.

Main weakness

The whole system has to be controlled on a regular basis to be efficient, hence the system is sophisticated and requires skilled labour, energy, technical equipment and chemicals.

Applicability

Centralised drinking water treatment plants are useful when water is supplied from a source containing natural or anthropogenic contaminants such as lakes, rivers, seas or groundwater. Many different types of raw water can be purified in treatment plants as processes are designed for each case considering water quality and desired capacity.

The treatment plants need to be maintained by skilled labour to regularly control water quality and optimise processes.

Smaller drinking water treatment plants may be installed at semi-centralised level or point of use in order to minimise energy requirements for distribution.
